Construction Graphics: A Practical Guide to Interpreting Working Drawings, 2nd Edition

The Second Edition of this highly visual text brings together sketching, plan reading, and working drawing as they are used in the construction process. Hundreds of details from actual and idealized working drawings, with explanatory photographs and drawings, show how construction graphics "translate" into construction methods and practices. The new edition includes more material on basic plan reading, new coverage plan examples including residential and commercial plan details.
